PR electronics 5350 - Electrical Specifications

22 23
*NB! Please remember to order PR sim pin type 8422
if the simulation mode function is to be used.
Electrical specifications:
Specifications range:
-40°C to +85°C
Common specifications:
Supply voltage, DC
Standard ................................................. 9.0...32 V
ATEX, FM, UL and CSA .......................... 9.0...30 V
In FISCO installations ............................. 9.0...17.5 V
Consumption ............................................... < 11 mA
Max. current increase in
the event of an error ............................... < 7 mA
Isolation voltage, test .................................. 1.5 kVAC for 60 s
Isolation voltage, operation ......................... 50 VRMS / 75 VDC
Warm-up time .............................................. 30 s
Signal / noise ratio ...................................... Min. 60 dB
Response time (programmable) .................. 1...60 s
Updating time .............................................. < 400 ms
Execution time, analogue input ................... < 50 ms
Signal dynamics, input ................................ 24 bit
Calibration temperature .............................. 20...28°C
Accuracy, the greater of general and basic values:
22
General values
Input type
Absolute
accuracy
Temperature
coefficient
All ≤ ±0.05% of reading ≤ ±0.002% of reading / °C
Vibration (DIN class B) ................................ IEC 60068-2-6 and IEC 60068-2-64
4 g / 2...100 Hz
Humidity ...................................................... < 95% RH (non cond.)
Dimensions .................................................. Ø 44 x 20.2 mm
Protection degree (enclosure / terminal) ..... IP68 / IP00
Weight ......................................................... 55 g
Electrical specifications, input:
RTD and linear resistance input:
Cable resistance per wire ............................ 50 Ω
Sensor current ............................................. Nom. 0.2 mA
Effect of sensor cable resistance
(3- / 4-wire) < 0.002 Ω / Ω
Sensor error detection ................................ Yes
Short circuit detection ................................. < 15 Ω
23
Basic values
Input type
Basic
accuracy
Temperature
coefficient
Pt100 and Pt1000 ≤ ±0.1°C ≤ ±0.002°C / °C
Ni100 ≤ ±0.15°C ≤ ±0.002°C / °C
Cu10 ≤ ±1.3°C ≤ ±0.02°C / °C
Lin. R ≤ ±0.05 Ω≤ ±0.002 Ω
/ °C
Volt ≤ ±10 µV ≤ ±0.2 µV / °C
TC type:
E, J, K, L, N, T, U
≤ ±0.5°C ≤ ±0.010°C / °C
TC type:
B, R, S, W3, W5
≤ ±1°C ≤ ±0.025°C / °C
EMC immunity influence ................................ < ±0.1% of reading
Extended EMC immunity:
NAMUR NE 21, A criterion, burst .................. < ±1% of reading
RTD
type
Min.
value
Max.
value Standard
Pt25...Pt1000
Ni25...Ni1000
Cu10...Cu1000
Lin. resistance
Potentiometer
-200°C
-60°C
-50°C
0 Ω
0 Ω
+850°C
+250°C
+200°C
10 kΩ
100 kΩ
IEC60751/JIS C 1604
DIN 43760
α = 0.00427
-
-
