EEx- / I.S.-godkendelse - 5350B:
KEMA 02ATEX1318 ..................................... II 1 GD el. II 2 (1) GD,
T65°C...T105°C
EEx ia IIC eller EEx ib [ia] IIC T4...T6
Må anvendes i zone .................................... 0, 1, 2, 20, 21 eller 22
FM, UL og CSA ........................................... IS, Class I, Div. 1, Group A, B, C, D
IS, Class I, Zone 0/1, Group IIC
IS, Class I, Div. 2, Group A, B, C, D
Ex- / I.S.-data:
Signaludgang / forsyning, terminal 1 til 2:
Max. omgivelsestemperatur er afhængig af den tilsluttede barrieres
P
o
.
Enhed
5350B
Zone 0, EEx ia IIC, Entity / Fisco
IS, Class I, Division 1, Group A, B, C, D
Entity / Fisco
Barriere med
P
o
< 0,84 W
Barriere med
P
o
< 1,3 W
Kan anvendes i
FISCO-systemer
Kan anvendes i
FISCO-systemer
U
i
I
i
P
i
L
i
C
i
T1...T4
T5
T6
30 VDC
120 mADC
0,84 W
1 µH
2,0 nF
T
omg.
< 85°C
T
omg.
< 70°C
T
omg.
< 60°C
30 VDC
300 mADC
1,3 W
1 µH
2,0 nF
T
omg.
< 75°C
T
omg.
< 65°C
T
omg.
< 45°C
17,5 VDC
250 mADC
2,0 W
1 µH
2,0 nF
T
omg.
< 85°C
T
omg.
< 60°C
T
omg.
< 45°C
15 VDC
900 mA
5,32 W
1 µH
2,0 nF
T
omg.
< 85°C
T
omg.
< 60°C
T
omg.
< 45°C
Enhed
5350B
Zone 1, EEx ib IIC, Entity / Fisco
IS, Class I, Division 2, Group A, B, C, D
Entity / Fisco
Barriere med
P
o
< 5,32 W
FISCO seg-
mentkobler
U
i
I
i
P
i
L
i
C
i
T1...T4
T5
T6
30 VDC
250 mADC
5,32 W
1 µH
2,0 nF
T
omg.
< 85°C
T
omg.
< 75°C
T
omg.
< 60°C
17,5 VDC
alle
alle
1 µH
2,0 nF
T
omg.
< 85°C
T
omg.
< 75°C
T
omg.
< 60°C
Følerindgang, terminal 3, 4, 5 og 6:
U
o
................................................................ : 5,7 VDC
I
o
................................................................. : 8,4 mA
P
o
................................................................ : 12 mW
L
o
................................................................ : 200 mH
C
o
................................................................ : 40 µF
GOST R godkendelse:
Standard: VNIIM .......................................... Cert. no. Ross DK.ME48.V01899
Ex: VNIIFTRI ................................................ Cert. no. Ross DK.GB06.V00100
Ex permit ..................................................... РРС00-17800
Overholdte myndighedskrav: Standard:
EMC 2004/108/EF
Emission og immunitet ....................... EN 61326-1 : 2006
ATEX 94/9/EF .............................................. EN 50014 : 1997, EN 50020 : 2002,
EN 60079-15 : 2003, EN 50284 : 1999
EN 60079-27 : 2005
FM ............................................................... 3600, 3610, 3611
UL ................................................................ UL 508, UL 1604, UL 913,
UL 60079-0, UL 60079-1
CSA, CAN / CSA ......................................... C22.2 No. 142, No. 157, No. 213,
CAN / CSA .................................................. E79-0, -11, -15
ANSI / UL .................................................... UL 60079-0, -11, -15
