9202 - Product Version 9202-003 15
Signal error and cable fault indications without display front
List of LED and error signal indications
State Green LED
Ch. 1:
Yellow / red
Ch. 2:
Yellow / red
Status relay,
N.C.
Power rail
signal status
Module OK Flashing Energised OFF
No supply OFF OFF OFF De-energised ON
Module defective OFF Red Red De-energised ON
Channel 1, relay energised Flashing Yellow Energised OFF
Channel 1, relay de-energised at cable fault Flashing Red flashing De-energised ON (if activated)
Channel 1, relay de-energised Flashing OFF Energised OFF
Channel 2, relay energised Flashing Yellow Energised OFF
Channel 2, relay de-energised at cable fault Flashing Red flashing De-energised ON (if activated)
Channel 2, relay de-energised Flashing OFF Energised OFF
