PR electronics 9202 User Manual

9202 - Product Version 9202-003 9
Accessories
Electrical specifications
Environmental conditions
Specifications range ............................................... -20...+60°C
Storage temperature .............................................. -20...+85°C
Calibration temperature ........................................ 20...28°C
Relative humidity..................................................... < 95% RH (non-cond.)
Protection degree .................................................... IP20
Installation in ............................................................. Pollution degree 2 & measurement /
overvoltage category II
Mechanical specifications:
Dimensions (HxWxD) .............................................. 109 x 23.5 x 104 mm
Dimensions (HxWxD) w/ 4501 / 4511 ........... 109 x 23.5 x 116 / 131 mm
Weight approx. .......................................................... 170 g
Weight incl. 4501 / 4511 (approx.) .................. 185 g / 270 g
DIN rail type ............................................................... DIN EN 60715 / 35 mm
Wire size ...................................................................... 0.13...2.08 mm
2
AWG 26...14
stranded wire
Screw terminal torque ........................................... 0.5 Nm
Vibration ...................................................................... IEC 60068-2-6 : 2007
Vibration: 2...13.2 Hz .............................................. ±1 mm
Vibration: 13.2...100 Hz ........................................ ±0.7 g
Order: 9202B
Type Switch Channels
9202B Opto........ : 1
Relay N.O. .. : 2
Relay N.C.... : 3
Single ....: A
Double ...: B
Type Description
4501
4511
9400
9404
9410
9420
Display / programming front
Communication enabler
Power rail
Module stop for rail
Power control unit
Power supply 24 V / 120 W - Ex nAC
