Digit height:
5515A (LED) ................................................ 14.2 mm
5515B (LCD) ................................................ 16 mm
Display update ............................................ 2.5 times/s
Backlight (LCD) ........................................... Light green
Input outside input range is
indicated by:
Nominal min. - 7% of span ......................... In.LO
Nominal max. + 3.5% of span .................... In.HI
Sensor error is indicated
in display by ................................................ SENS
Readout > 9999 is indicated by .................. flashing 9999
GOST R approval:
VNIIM ........................................................... Cert. no. Ross DK.ME48.V01899
Observed authority requirements: Standard:
EMC 2004/108/EC
Emission and immunity ....................... EN 61326
LVD 73/23/EEC ............................................ EN 61010-1
PELV/SELV ................................................... IEC 364-4-41
EN 60742
Of span = Of the presently selected range
29
RTD / lin. R input:
Cable resistance per wire (max) .................. 10 Ω
Sensor current ............................................. Nom. 0.2 mA
Basic accuracy ............................................ ±0.2°C
Temperature coefficient:
span < 100°C ........................................... ±0.01°C/°C
amb.
span > 100°C ........................................... ±0.01% of span / °C
amb.
Effect of sensor cable resistance
(3- / 4-wire) .................................................. < 0.002 Ω/Ω
Sensor error detection (only RTD) ............... Indicated in display
Electrical specifications - INPUT type 5515-2:
Voltage input:
Measurement range ................................... 0...250 VDC
Min. measurement range (span) ................. 50 mVDC
Max. offset .................................................. 50% of selected max. value
Input resistance ≤ 2.5 VDC ....................... Nom. 10 MΩ
> 2.5 VDC ........................ Nom. 5 MΩ
Current input:
Measurement range .................................... 0...100 mA
Min. measurement range (span) ................. 4 mA
Max. offset .................................................. 50% of selected max. value
Input resistance:
Supplied unit ............................................... 10 Ω + PTC (10 Ω)
Non-supplied unit ........................................ Shunt ∞, V drop < 6 V
Display:
Display readout ........................................... ±9999 (4 digit)
Min. display readout (span) ......................... 0 counts
Decimal point .............................................. Programmable from front
28
Min. Max. Min. Max. offset
Type value value span of selec. max. value Standard
Pt100 -200°C +850°C 25°C 50% IEC 60751
Nl100 -60°C +250°C 25°C 50% DIN 43760
Lin. R 0 Ω 5000 Ω 30 Ω 50% -----
