PR electronics PReview 5515 - Electrical Specifications; Specifications Range; Common Specifications; TC Input Specifications

Electrical specifications - INPUT type 5515-1:
TC input:
Max. offset .................................................. 50% of selected max. value
Sensor current ............................................. Nom. 100 nA
Basic accuracy:
type E, J, K, L, N, T, U ............................. < ±1°C
type B, R, S, W3, W5 .............................. < ±2°C
Compensation accuracy (CJC) ................... < ±1°C
Temperature coefficient
Type E, J, K, L, N, T, U:
span < 500°C ........................................... ±0.05°C / °C
amb.
span > 500°C ........................................... ±0.01% of span/°C
amb.
Type B, R, S, W3, W5 .................................. ±0.2°C / °C
amb.
Sensor error detection ................................ Indicated in display
mV input:
Measurement range .................................... 0...100 mV
Min. measurement range ............................ 5 mV
Max. offset .................................................. 50% of selected max. value
Input resistance ........................................... Nom. 10 MΩ
27
ELECTRICAL SPECIFICATIONS:
Specifications range:
-20°C to +60°C
Common specifications:
Supply voltage:
5515--A ....................................................... 103.5...126.5,
50...60 Hz
5515--B ....................................................... 207...253 VAC,
50...60 Hz
5515--D ....................................................... 19.2...28.8 VDC /
21.6...26.4 VAC,
50...60 Hz
Internal consumption:
5515 A LED ................................................. < 3 W
5515 B LCD ................................................. < 1.5 W
Isolation voltage test / operation ................. 3.75 kVAC / 250 VAC
Communication ........................................... Loop Link
Signal dynamics, input ................................ 20 bit
Response time (programmable) .................. 1...60 s
Calibration temperature .............................. 20...28°C
Linearity error .............................................. < ±0.1% of span
Temperature coefficient ............................... < 0.01% of span / °C
Effect of supply voltage change ................. ≤ 0.002% of span / % V
Auxiliary voltage 5515 A2/B2:
2-wire supply ............................................... ≥ 20 VDC/20 mA
EMC immunity influence ............................. < ±0.5% of span
Max. wire square ......................................... 1 x 2.5 mm
2
stranded wire
Screw terminal torsion ................................ 0.5 Nm
Relative air humidity .................................... < 95% RH (non-cond.)
Dimensions (HxWxD) ................................... 48 x 96 x 120 mm
Cut out ........................................................ 44.5 x 91.5 mm
Tightness (mounted in panel front) ............. IP65
Weight ......................................................... 210 g
26
Max.
temp.
+1820°C
+1000°C
+1200°C
+1372°C
+900°C
+1300°C
+1760°C
+1760°C
+400°C
+600°C
+2300°C
+2300°C
Standard
IEC584
IEC584
IEC584
IEC584
DIN43710
IEC584
IEC584
IEC584
IEC584
DIN43710
ASTM E988-90
ASTM E988-90
Min. span
(5 mV)
200°C
50°C
50°C
50°C
50°C
100°C
200°C
200°C
50°C
75°C
200°C
200°C
Min.
temp.
+400°C
-100°C
-100°C
-180°C
-100°C
-180°C
-50°C
-50°C
-200°C
-200°C
0°C
0°C
Type
B
E
J
K4
L
N
R4
S
T
U
W3
W5
