13/21
114-120
Colour 7/white
121-127
white
128-191
Rainbow rotation speed from slow to
fas
192-255
Rainbow reverse rotation speed f slow
to fas
9 10 14
Fixed Gobo
Wheel
000-016
White
017-032
Gobo1
033-048
Gobo 2
049-064
Gobo
065-080
Gobo 4
081-096
Gobo
128-149
Rotation speed from slow to fas
150-171
Reverse rotation from slow to fas
172-183
Gobo 1 shake speed from slow to fas
184-195
Gobo 2 shake speed from slow to fas
196-207
Gobo 3 shake speed from slow to fas
208-219
Gobo 4 shake speed from slow to fas
shake speed from slow to fas
232-243
Gobo 6 shake speed from slow to fas
244-255
Gobo 7 shake speed from slow to fas
Linearly zooming
16
Zoom Fine 000-25
Zoom in 16 Bit precision
11 12 17
Pan 000-25
Pan rotation
13 18
Pan Fine 000-25
Pan rotation in 16 bit precision
12 14 19
Til
Tilt rotation
15 20
Tilt Fine 000-25
Tilt rotation in 16 bit precision
16 21
Pan & Tilt
speed
000-25
Pan&Tilt speed from fast to slow
13 17 22
Control
000-047
Reserved
048-080
Rese
081-112
Reserved
113-144
Lamp off ( stop in DMX value for 10 s)
145-168
Reserved
169-200
Lamp power reduced to 50%
201-223
Reserved
224-255
Lamp on (See remark below)
Remark:
If you intend to turn on/off the lamp via the last channel of the controller, don’t attempt to push the channel to value
224-255 immediately after turning it off, or push the slide bar to value 224-255 to wait it cooling. Under these 2
circumstances, the lamp can not be turned on. The right operation is: turn it off---cool down---push the slide bar to turn it
on.
