8.3.3 Demarcation of slopes >35% (Fig. 15)
• The boundary to slopes >35% must be at least 40
cm, as shown in Fig. 15.
• If you do not maintain this distance, there is a risk
that the robotic lawnmower (1) will drive out of the
demarcated area.
Thus, no function is possible any more, as the ro-
bot no longer has any orientation.
m NOTE:
When you have completely staked out the work-
ing area, connect the boundary wire (11) to the
charging station (10) as described in point 8.2.
m ATTENTION!
Fix the charging station (10) in place with the
help of a hammer (not included in delivery) and
the anchor pegs (13) only after you have staked
out the complete working area.
8.4 Connecting the charge station (10) (Fig. 16)
• Connect the 2-pin connector to the charging sta-
tion (10) as shown in gure 16 and screw it in place.
• Then plug the mains plug into the socket.
m ATTENTION!
Make sure that the boundary wire (11) is correct-
ly routed and the power supply unit (14) is cor-
rectly connected to the charging station (10) be-
fore connecting the plug to the mains.
If the charging station (10) is connected to the mains,
LED 1 lights up green on the rear part of the charging
station (10) (Fig. 17/20).
8.3.2 Laying the boundary wire around obsta-
cles (islands) (Fig. 14)
m NOTE:
A pond or pool must be demarcated from the mow-
ing area.
For large and heavy objects listed below as exam-
ples, an “island installation” is not necessarily re-
quired:
- Tree
- Raised bed
- Large/heavy plant buckets
- Greenhouse
- Garden shed
To protect delicate/small objects from damage, lay
the boundary wire (11) as follows:
• Run the boundary wire (11) along the outer edge
until you have reached the point with the short-
est distance (but at least 0.8 m) between the outer
edge and the obstacle.
• Lay the boundary wire (11) like a “supply line” along
the shortest path to the obstacle.
• Lay the boundary wire (11) at a distance of 30 cm
or 8 cm (see point 8.3.1) around the obstacle.
• Lay the cable along the “feed line” back to the out-
er edge.
m ATTENTION!
Do NOT allow the boundary wire (11) to cross.
The maximum distance between the boundary
wires is 5 mm.
• Continue to lay the cable along the outer edge.
8.4.1 Description of the status LED (Fig. 20)
LED status Meaning Remedy
LED 1 Does not illuminate no power supply. Make sure that the mains cable is properly connected
to the battery charger and that the battery charger is
connected to a suitable power supply.
Illuminates green The boundary wire is
connected correctly. The
robot is fully charged.
-
Flashes green The robot is charging. -
Flashes red The boundary wire
is damaged or not
connected properly.
Check that both ends of the boundary wire are
connected and that the cable clamp is reliable. Check
that the boundary wire has not been broken.
LED 2 Does not illuminate Wi-Fi not connected. Re-start the charging station.
Illuminates green Wi-Fi connected. -
LED 3 Does not illuminate Super-Link not
connected.
Dock the mower again.
Illuminates green Super-Link connected. -
Flashes green Super-Link connecting. -
