3.3 Wiring the Auxiliary Input and Output
Optional Varistor
COMMON
POWER SUPPLY
12V – 24V AC/DC
Auxiliary Relay
(-)
(+)
(-)
IN / MONITOR
N.C.
N.O.
COM
REX2 / White
NO(2) / Yellow
NC(2) / Orange
COM(2) / Blue
- / Black
+ / Red
