PRASTEL EASYBKA - 3.2 WIRING THE LOCK STRIKE RELAY AND REX

EASYBKA - EASYBKR
ENGLISH
ISEASYBK_08_18.pdf.docx
33
3.2 Wiring the Lock Strike Relay and REX
Optional Varistor
ELECTRIC LOCK
STRIKE
FAIL SAFE
or
FAIL SECURE
COMMON
POWER SUPPLY
12V – 24V AC/DC
(+)
(-)
(-)
(+)
(-)
- / Black
+ / Red
REX1/BL / Green
COM(1) / Violet
NO(1) / Gray
