EASYBKA - EASYBKR
ENGLISH
ISEASYBK_08_18.pdf.docx
32
Terminal
block
(EASYBKR)
Color
(EASYBKA)
Description
+
Red
Power supply (12-24V)
-
Black
Ground
REX1/BL
Green
REX/BL
COM
Purple
Main relay : COM
NC
Brown
N.C.
NO
Gray
N.O.
REX2
White
IN/Monitor
COM
Blue
Aux. Relay : COM
NC
Orange
N.C.
NO
Yellow
N.O.
3. Trim and cover all conductors that are not used.
Two typical wiring diagrams are shown on the next pages.
