8 Data transfer ■
65
8 Data transfer
The moisture analyser is equipped with an RS232/V24 interface for
data transfers to peripheral instruments.
Before the data transfer, the RS232 interface must be matched with
the one in the peripheral instrument in the instrument's configuration
menu (see chapter 5.3.10 "Interface functions").
• Handshake
The handshake is set in the factory to "NO". It can be set to software
handshake XON/XOFF or to hardware handshake.
• Baud rate
Possible baud rates: 300, 600, 1200, 2400, 4800, 9600 or
19200 baud.
• Parity
Possible parity: 7-even-1 stop, 7-odd-1 stop, 7-no-2 stop or
8-no-1 stop, *8 even 1 stop or *8 odd 1 stop.
(* setting not available for firmware Nxx).
• Display
Data transfer takes place in ASCII code:
Pos.012345678910
7-even-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA PB SP -
7-odd-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA PB SP -
7-no-2 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 1.SP 2.SP -
8-no-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 8.DA SP -
8-even-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 8.DA PB SP
8-odd-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 8.DA PB SP
SB: Start bit PB: Parity bit
DA: Data bit SP: Stop bit
S D7 D6 D5 D4 D3 D2 D1 D0 U U U
123456789101112131415.........
B B B S D7D6D5D4D3D2D1DPD0 B U ... CR LF
