CARRIAGE FEED GEARBOX
NOTE
Dimensions are in mil-
limeters.
All gears: pressure angle
20 degrees, module
M2.25.
Bearings: reference
numbers in this list may
not be recognized by
stockists.
If replacing a bearing
or oil seal, remove and
measure the item in
queson. Order replace-
ment parts from Quality
Machines.
Ref. Mfr. No. Description Qty. Ref. Mfr. No. Description Qty.
1 Oiler 1 51 3060E Front panel 1
2 Screw: M6 x 12 skt hd 7 52 3071D Oil seal 1
3 3034B Input shaft (1) flange 1 53 3059D Faceplate 1
4 3035C Oil seal 1 54 3042C Back plate 1
5 89103 Ball bearing: 17 x 35 x 10 8 55 3070C Oil seal 1
6 Key: 5 x13 1 56 3001C Gearbox casting 1
7 3041B Input shaft (1) 1 57 Screw: M6 x 12 skt hd 6
8 Key: 6 x 90 3 58 Pin: 5 x 25 2
9 3005B Gear: triple, 18/X/18 2 59 Washer: M10, spring 2
10 3066B Spacer 2 60 Screw: M10 x 30 skt hd 2
11 Screw: M6 x 8 set 1 61 Screw: M6 x 12 skt hd 1
12 3027C Gear: 27T 1 62 Spacer: 6 x 32 x 5 1
13 Key: 6 x 15 1 63 B1260 Bushing 1
14 Key: 6 x 35 1 64 3016C Gear: 17T 1
15 3067B Shaft 1 65 Screw: M6 x 16 set 1
16 3025C Gear: 21T 1 66 3015C Shaft 1
17 89102 Ball bearing: 15 x 32 x 9 3 67 Oil seal: 22 x 2.65 1
18 3017B Plug 3 68 3014C Gear: 15T 1
19 3044B Shaft end cap 2 69 3022F Sleeve 1
20 3046B Oil seal 2 70 3086D Oil seal 1
21 3045B Bushing 1 71 Screw: M6 x 25 skt hd 5
22 3033B Shaft (2) 1 72 3013E Shaft 1
23 3029B Gear: 24T 1 73 Oil seal: 18 x 30 x 10 1
24 3031B Gear: 16T 1 74
Plug, oil fill, M16/1.5
2
25 3032B Gear: 18T 1 75
Oil seal: 16 x 2.4
2
26 3003B Gear: 20T 1 76 Screw: M8 x 15 skt hd 8
27 3030B Spacer 1 77 Screw: M6 x 10 set 1
28 3002B Gear: 28T 1 78 3012D Bushing 1
29 3026C Gear: pair 18T/30T 1 79 7003B Support bracket 1
30 3007C Gear: 22T 1 80 Screw: M4 x 20 skt hd 2
31 3008C Spacer 1 81 3011D Shaft 1
32 Circlip 2 82 3050C Shift fork 1
33 89103 Ball bearing: 17x 35 x 10 1 83 3049C Shift fork 2
34 3009B Gear: 23T 1 84 3089A Shaft, gear shifters 2
35 Key: 5 x 40 1 85 O-ring seal: 12 x 1.8 4
36 3019C Shaft 1 86 Screw: M4 × 6 set 2
37 3004B Shaft (3) 1 87 3062C Shift fork 1
38 Key: 5 x 35 1 88 Screw: M3 x 6 skt hd 12
39 Circlip 1 89 2060 Pointer disk 4
40 3006C Gear: pair 15T/22T 1 90 Screw: M8 × 6 set 4
41 Pin: 5 x 6 2 91 Spring: 1 x 5 x 25 4
42 3018C Gear: 21T 1 92 Steel ball: Ø5 4
43 8103 Thrust bearing: 17 x 32 x 8 1 93 Screw: M6 x 10 skt hd 4
44 3084D Leadscrew flange 1 94 Washer 4
45 3068D Oil seal 1 95 3054F Knurled knob 4
46 8104 Thrust bearing: 20 x 35 x 10 1 96 Key: 5 x 8 4
47 3021C Shaft. leadscrew drive 1 97 3088 Gear, shift fork drive 4
48 Nut: M20 x 1.5, special 2 98 A12 Sight glass 1
49 Pin: 5 x 6 1 99 O-ring seal: 16 x 2.4 4
50 3020E Leadscrew connector 1
To Next Page
