Precision matthews PM-1440BV - Page 37

37PM-1440BV v3 2020-10 Copyright © 2020 Quality Machine Tools, LLC
Dimensions in millimeters
Ref Description Part
1 Headstock main casting Z3200
2 Front casting Z3201
3 Socket head screw M6×40 Z3202
4 Pin 5×40 Z3203
5 Flanged bearing Z3204
6 Plate Z3205
7 Screw M4×8 Z3206
8 Shaft Z3207
9 Retaining ring 12 Z3208
10 Socket head screw M6×20 Z3209
11 Cover plate Z3210
12 Gasket Z3211
13 Oil seal SD25X40X7 Z3212
14 Ball bearing 6005/P5 Z3213
15 Shaft Z3214
16 Key 6×120 Z3215
17 Shaft/gear Z3216
18 Key 6×50 Z3217
19 Gear Z3218
20 Gear Z3219
21 Retaining ring 35 Z3220
22 Retaining ring 22 Z3221
23 Ball bearing 6203 Z3222
24 Plug Z3223
25 Screw M8×16 Z3224
26 O-ring 40×3.1 Z3225
27 Socket head screw M6×25 Z3226
28 Socket head screw M4×12 Z3227
29 Cover plate Z3228
30 Gasket Z3229
31 Ball bearing 6204 Z3230
32 Washer Z3231
33 Gear Z3232
34 Gear Z3233
Ref Description Part
35 Gear Z3234
36 Key 8×55 Z3235
37 Shaft/gear Z3236
38 O-ring 47×3.1 Z3237
39 Spanner nut Z3238
40 Collar Z3239
41 Cover plate Z3240
42 Gasket Z3241
43 Tapered roller bearing 30210/P5 Z3242
44 Gear Z3243
45 Gear Z3244
46 Key 8×18 Z3245
47 Gear Z3246
48 Retaining ring 90 Z3247
49 Tapered roller bearing 30212/P5 Z3248
50 Front ange Z3249
51 Gasket Z3250
52 Key 6×40 Z3251
53 Key 8×85 Z3252
54 Spindle Z3253
55 O-ring 25×2.4 Z3254
56 Shaft Z3255
57 Retaining ring 42 Z3256
58 Ball bearing 16004 Z3257
59 Gear Z3258
60 Retaining ring 20 Z3259
61 Shaft Z3260
62 Oil seal 24×32×5 Z3261
63 Washer Z3262
64 Socket head screw M5×16 Z3263
65 Collar Z3264
66 Gasket Z3265
67 Gear Z3266
HEADSTOCK COMPONENTS Fig 5
