Precision Power DCX 300.2 - Features; QBASS PLUS Specifications

FEATURES
New! Advanced Instrumentation Input Stage.
New! 24dB/Octave; HP/LP/FULL; 30-4kHz Crossover.
New! Independent Line Output Crossover 30-4kHz
PWM Power Supply
Triple Darlington Output Stage.
AP-IV Protection Circuity
QBASS
TM
Bass Boost
High Voltage Input Capability with -12dB Attention Switch.
Gold Plated RCA Input and Output Connectors.
PowerLock
TM
Speaker and Power Wire Connectors.
2 Yr Warranty; if installed by an Authorized PrecisionPower Dealer.
QBASS PLUS SPECIFICATIONS
QBASS PLUS
TM
Up to 18dB of boost with selectable center frequency at 30Hz, 36Hz,
44Hz or 60Hz, with a Q-factor of 2.
Optional
QBASS REMOTE
TM
This boost control can be mounted in the dash and will supersede
the boost control on the amplifier endplate.
