Precision Power PCX 4125 - Page 2

MODEL 4ohm STEREO 2ohm STEREO 4ohm MONO
PCX 440 4 X 40 4 X 80 2 X160
PCX 480 4 X 80 4 X 160 2 X 320
PCX 4125 4 X 125 4 X 250 2 X 500
PCX 5800 4 X 50 4 X 100 2 X 200
4ohm MONO 2ohm MONO
5/Ch. 1 X 200 1 X 400
1
28
* ALL POWER RATINGS SHOWN ARE TESTED @ 12V; 4 ; 20-20kHz
NEW! Advanced Instrumentation Input Stage.
NEW! TC-X Crossover 12dB/Octave; HP/LP/FULL; 30-4kHz Crossover.
Adaptive PWM Power Supply. (PCX 440, PCX 480, PCX 5800)
Fully Regulated PWM Power Supply.(PCX 4125)
Fully Complimentary Triple Darlington Output Stage.
AP-IV Protection Circuitry. (PCX 440, PCX 480, PCX 5800)
AM-V Protection Circuitry. (PCX 4125)
Forced Air Thermal Management.
QBASS™ Bass Boost (PCX 440)
QBASS Plus™ Bass Boost. (PCX 480, PCX 4125, PCX 5800)
High Voltage Input Capability with -12dB Attenuation Switch.
Gold Plated RCAInput and Output Connectors.
PowerLock™ Speaker and Power Wire Connectors.
Mixed Mono/Stereo Operation.
3-Yr Warranty; installed by an Authorized PrecisionPower Dealer.
Designed and Handcrafted in the USA.
Power Bandwidth 10 Hz - 50 kHz
Total Harmonic Distortion > 0.02 %
S/N Ratio < 110dB
Input Topology Instrumentation
Input Sensitivity 150mv - 12 Volts RMS
Input Impedance 10k Ohms
Load Impedance (stereo) 2 - 8 Ohms
Load Impedance (bridged) 4 - 8 Ohms
Supply Voltage 11 - 15 Volts
Damping Factor > 500
Slew Rate > 50 V/µS
QBASS™ Up To +12dB @ 40Hz
QBASS PLUS™ Up To +18dB Boost
@ 30, 36, 44, or 60Hz
Crossovers 12dB/Octave
Crossover Frequency 30-4kHz
Idle Current: PCX 440 2 Amps
PCX 480 2.5 Amps
PCX 4125 3 Amps
PCX 5800 2.5 Amps
