Table of contents
D 159195 © Precitec GmbH & Co. KG • EN 09/2019
vii
6 Specific characteristics of the 3D version 6 - 51
6.1 LightCutter 3D 6 - 51
6.1.1 Product view
6 - 51
6.1.2 Technical specifications
6 - 52
6.1.3 Mechanical dimensions
QBH version (F150)
6 - 53
6.1.4 Media connections
6 - 54
6.2 Installation
(integration into the machine)
6 - 55
6.2.1 Fitting the ceramic part
and nozzle
(only in the case of individual parts delivery)
6 - 55
6.2.2 Connecting the laser fibre to the laser head
(trained personnel only)
6 - 56
6.2.3 Fixing the cutting head to the machine
(trained personnel only)
6 - 57
6.2.3.1 Laser head - hole pattern
6 - 57
6.2.3.2 Grounding the laser head
6 - 58
6.2.3.3 Aligning the sensor insert
(HF socket, sensor system)
6 - 59
6.3 Maintenance 6 - 60
6.3.1 Replacing the ceramic part and nozzle
(sensor area)
6 - 60
6.3.2 Maintaining and replacing the sensor insert (SE)
6 - 61
6.4 Parts available
(LightCutter 3D only)
6 - 62
7 Error analysis and diagnostics 7 - 63
7.1 Safety notes 7 - 63
7.2 Malfunctions 7 - 63
7.2.1 Electrical malfunctions
7 - 63
7.2.2 Mechanical malfunctions
7 - 64
8 Appendix 8 - 65
8.1 Basic technical information 8 - 65
8.1.1 Conversion of Units
8 - 65
8.1.2 Compressed air quality
(ISO 8573-1)
8 - 65
8.1.3 Cooling water - Dew point temperature
8 - 65
8.1.4 Running cables
(notes)
8 - 66
8.2 Parts available 8 - 67
AM YW30 CL R / P0253-1406-00001
