Precor 9.23 Service Manual

9.23, 9.27 Treadmill
Page 14
Diagram 4.3 - Drive Motor Mounting
6. Plug the AC power cord into the AC outlet and set the treadmill circuit breaker in the “on”
position.
7. Check treadmill operation per Section 3.
Belt Tension Adjustment Bolt

Precor 9.23 Specifications

General

Incline Range	0% to 15%
Decline	Not available
Motor	3.0 HP
Speed Range	0.5 to 12 mph
Heart Rate Monitoring	Touch sensor
Weight Capacity	350 lbs
Dimensions	54" H
Display	LCD display with feedback
