Precor C954 - Procedure 4.1 - Calibrating the Lift Motor

C954, C956 Treadmill
Page 1-14 Page 14
Procedure 4.1 - Calibrating the Lift Motor
1. Set the treadmill circuit breaker in the “off” position and unplug the line cord from the wall
outlet.
2. Remove the hood.
3. Place the treadmill on its right side. Remove hitch and clevis pins that secure the lift tube to
the lift platform. See Diagram 4.1.
Diagram 4.1 - Lift Motor Mounting
Hitch Pin
See Step 8
Hitch Pin
Clevis Pin
Lift Tube
Drive Screw
Clevis Pin
