Precor C966i Owner's Manual

page 29
COMMERCIAL PRODUCTS DIVISION
KEYS ON THE DISPLAY CONSOLE
The Precor treadmills have an easy-to-use keypad that is activated by the slightest
touch. Remind users that they only need to apply gentle pressure to these ultra-
sensitive keys.
Each key on the display console’s keypad provides specific functions. Numeric keys
(numbered 1 - 0) let you enter data in answer to the display prompts and change the
speed or incline during a workout. The standard keys, CHANGE, RESET,
INCLINE ▲▼, SPEED CONTROL ▼▲, and ENTER, let you enter data as well as
control your workout.
The following information explains the different uses of the keys from left to right.
To locate each key, look at the display console or refer to Diagram 22.
Diagram 22 Display console keypad.
Numeric keys: Indicate program #,
time limit, or goal entries. During a
workout, use these keys to select a
target speed or incline.
Note: The CHANGE keys are not shown in this diagram. Refer to Diagram 21.
QUICKSTART: Bypasses the remaining
Setup prompts and starts moving the
running belt. SmartRate
®
is inactive and
default values apply.
KEYPAD TIPS
• Select accurate entries or features such as SmartRate
®
will not work properly.
• Answer the Setup prompts by pressing the numeric keys or the ▼ or ▲ keys.
• Press ENTER to select the information being displayed.
• QUICKSTART bypasses further selections and causes the running belt to start
moving. Default values apply (see QUICKSTART on page 30). The SmartRate
®
display does not blink or flash, or give any indication of the zone that you are in.
• A time-out occurs during the Setup prompts if the treadmill detects no key
presses for 5 seconds. Prompts appear requesting that the user press the
arrow or number keys. If no key presses occur within the next 2 minutes, the
display returns to the Precor banner.
• Press RESET to return to the Precor banner.
• The STOP button does not appear in Diagram 22, but its function is vital as
explained in this section.

Precor C966i Specifications

Power and Motor

motor power	4.0 hp continuous duty
power requirements 120v	120 v @ 50/60Hz 20 Amps
power requirements 240v	240v @ 50/60Hz 20 Amps

Performance

speed range	0.5 to 16 mph (1 to 26 kph)
incline range	-3% to 15% grade

Weight and Dimensions

length	86 inches (218 cm)
width with handrails	37 inches (93 cm)
width without handrails	34 inches (86 cm)
height	59 inches (150 cm)
weight	375 lbs (170 kg)
shipping weight	470 lbs (213 kg)
running surface	60 inches x 20 inches (153 cm x 51 cm)
