Assembly Requirements
To assemble the equipment, follow the steps in the order listed in this assembly
guide. For mor
e pr
oduct information, visit us at www.pr
ecor.com.
WARNING
At least two people ar
e r
equir
ed to assemble the equipment.
DO NO
T attempt assembly b
y yourself.
When assembling the equipment, we recommend you:
• Unpack the box and assemble the equipment close to where you plan to use it.
• Locate the equipment at least 40 inches (1 meter) away from walls or furniture
on either side of the equipment, and 40 inches (1 meter) away from objects
behind or in front of the equipment.
• Assemble the equipment on a solid, at surface, so that it remains level and
stable.
Required tools
• Torque wrench
• Rubber mallet
• 18 mm open-end wrench
• 19 mm open-end wrench
Counter
weight
Cable arm
Center
frame
Base frame
Rear upright
Weight
horns
Weight arm
weight horn
Shoulder frame
Shoulder
frame
support
Height
adjustment
assembly
Shoulder pad
Long placard
Short placard
Weight arm
To Next Page
