Precor Discovery DPL0624 User Manual

Hardware kit
Component Quantity
Socket head cap bolt
(M12 × 35 mm)
10
Flat washer (13 x 26 mm)
12
Socket head cap bolt
(M12 × 25 mm)
6
Socket head cap bolt
(M12 × 75 mm)
2
Set Screws (M8 x 6 mm)
4
Flat washer (11 x 23 mm) black 6
Flat washer (12.2 x 30 mm)
6
End cap
4
Button head cap bolt
(M8 x 15 mm)
5
Flat head bolt (M12 × 30 mm)
4
Hex key (8 mm) 2
Hex key (10 mm)
1
Flat head hex screw
(M8 x 20 mm)
6
Component Quantity
Flat head hex bolt (M12 x 70 mm)
2
Button head bolt (M10 x 25 mm)
black
6
Socket head bolt (M8 x 25 mm) 2
Flat washer (9 x 16 mm) 7
TPU (rubber bumper) washer
4
Button head bolt (M10x16 mm) 2
Flat washer (M10 x 20 mm)
2
2
