Owner’s Manual: Display Console 17
Using the Center Display
SmartRate—Displays your heart rate as a blinking bar
which indicates the zone you are in when you grasp both
touch-sensitive grips. A heart icon blinks in the center
display when a heart rate is being detected. Refer to Using
SmartRate®.
PROGRAM PROFILE—In most programs, the resistance
setting affects the column height in the program profile as
shown in Figure 7. The profile raises or lowers according
to which arrow key is pressed.
Figure 7: Column height in the program profile
PROGRAM—Displays the current program selection. Refer
to Programs.
To Next Page
