Precor EFX 5.21 User Manual

EFX 5.21/ 5.23 Elliptical Fitness Crosstrainer Assembly Guide 2
Hardware Kit
Fasteners Quantity
(A) Hex head screw (M8 x 20 mm)
8
(B) Flat washer (M8)
8
(C) Buttonhead screw (M8 x 12 mm)
6
(D) Lock washer (M8)
6
(K) Phillips-head screw (M5 x 16 mm)
3
Additional Fasteners for EFX5.23 only Quantity
(E) Buttonhead screw (M10 x 20
mm)
2
(F) Flat washer (M10)
2
Additional Fasteners for EFX5.23 only Quantity
(G) Buttonhead screw (M8 x 50 mm)
2
(H) Flat washer (M8)
4
(J) Locknut (M8)
2
2 — Handlebar
caps (L)
(EFX 5.23 only)
2 - Moveable arm
cuffs (each cuff is
two pieces) (M) (EFX 5.23 only)
1 — Double-ended box wrench
2 — Hex key
1 — Power cord

Precor EFX 5.21 Specifications

General

Brand	Precor
Model	EFX 5.21
Category	Elliptical Trainer
Language	English
