©2019 Precor Inc. | Converging Chest Press RSL 414 | Assembly Guide
4
Part # Name Quantity Part # Name Quantity
Main frame 1 Weight plates 10 lb (4.5 kg) 23
Side arm, left 1 Collars 2
Side arm, right 1 End plugs with sleeves 2
Upper cross brace 1 Washers, 12.2 mm ID x 35 mm OD 2
Lower cross brace 1 Washers, domed, silver 2
Seat assembly 1 Washers, rubber, black 3
Shaft 1 Washer, silver 13.5 mm ID x 35 mm OD 1
Roller assembly 1 Retaining rings, 3/4-inch 2
Gas spring 1 Hole plugs 2
Bumpers 4 Button head cap screw (BHCS) M6 x 15 mm 1
Weight stack spacer, 1-inch 1 Socket head cap screws (SHCS) M12 x 25 mm 2
Add-on weight 5 lb (2.2 kg) 1 Washers, 9 mm 6
Weight stack tower frame 1 Washers, 13 mm 8
Kick plate 1 Hex head screws 5/16-inch x 1½-inch 6
Add-on weight handle 1 Socket head cap screws (SHCS) M12 x 35 mm 6
Top plate assembly 1 Socket head cap screws (SHCS) M12 x 130 mm 2
Shroud, crown 1 Nylon lock nuts, M12 2
Guide rods 2 Socket head cap screws (SHCS) M10 x 65 mm 2
Guide rod with cap 1 Nylon lock nuts, M10 2
Add-on weight spacer, 3-inch 1 Button head cap screws (BHCS) M10 x 125 mm 2
Shroud, rear middle 1 Socket head cap screws (SHCS) M10 x 40 mm 2
Shroud, rear lower 1 Washers, 11 mm 5
Shroud, rear upper 1 Back pad 1
Shroud, top tray 1 Seat pad 1
Shroud, front middle (left and right) 2 Weight labels 1
Shroud, front lower 1 Roller adjustment tool (attached to Seat assembly) 1
Shroud, front upper placard 1
Shroud, pulley cover 1
1
10
11
12
13
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
3
30
31
32
33
34
35
36
37
39
4
40
42
43
44
45
46
47
48
49
6
7
8
9
2
5
14
Parts List
38
41
50
51
52
53
54
6
