Page 2 For technical questions, please call 1-888-866-5797. ITEM 62201
Table of Contents
Specifications ............................................. 2
Safety ......................................................... 3
Setup .......................................................... 7
Operation ................................................... 12
Maintenance .............................................. 16
Troubleshooting ......................................... 20
Parts Lists and Diagrams .......................... 24
Warranties ................................................. 30
Specifications
Pressure Washer Specifications
Pump Axial
Drive Direct
Maximum Pressure 2500 PSI
Flow Rate 2.4 GPM
Hose Length 25'
Wand Length 21"
Nozzles
Quick Connect 0°, 15°,
25°, 40° + Soap Nozzle
Engine Specifications
Displacement 159 cc
Engine Type
Vertical Single Cylinder
4-stroke OHV
Cooling System Forced air cooled
Fuel
Type
87+ octane stabilizer treated
unleaded gasoline
Capacity 0.34 Gallon (1.3 Liter)
Engine Oil
Type SAE
10W-30 above 32° F
5W-30 at 32° F or below
Capacity 0.5 Quart (0.5 Liter)
Bore x Stroke 65 mm x 48 mm
Compression Ratio 8.4:1
Rotation viewed from PTO
(power takeoff - the output shaft)
Counterclockwise
Spark Plug
Type Torch
®
F5RTC
Gap 0.6 – 0.8 mm
Valve Clearance
Intake 0.10 – 0.15 mm
Exhaust 0.15 – 0.20 mm
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency and by the California Air Resources Board (also known as CARB).
For warranty information, refer to the last pages of this manual.
