Page 28 For technical questions, please call 1-888-866-5797. ITEM 62201
SAFETY SETUP OPERATION MAINTENANCE
Engine Parts List
Part Description Qty.
1B Bolt M6 x 14 10
2B Cylinder Head Cover 1
3B Valve Cover Gasket 1
4B Rocker Arm Assembly 2
5B Lock Nut 2
6B Nut 2
7B Rocker Arm 2
8B Rocker Arm Stud 2
9B Valve Spring Seat 2
10B Spring Valve 2
11B Intake Valve Seal 1
12B Exhaust Valve 1
13B Intake Valve 1
14B Bolt M8 x 54 4
15B Rocker Arm Base 1
16B Cylinder Head 1
17B Spark Plug 1
18B Stud M6 x 95 2
19B Muffler Gasket 1
20B Muffler 1
21B Muffler Guard 1
22B Flange Nut M6 4
23B Stud M6 x 87 2
24B Carburetor Insulator Gasket 1
25B Carburetor Insulator 1
26B Carburetor Gasket 1
27B Carburetor 1
28B Air Filter Gasket 1
29B Bolt M6 x 20 2
30B Air Filter Element 1
31B Air Filter 1
32B Cylinder Head Gasket 1
33B Dowel Pin Φ10 x 16 2
34B Push Rod 2
35B Tappet 2
36B Camshaft 1
37B Piston Ring Set 1
38B Piston Pin Circlip 2
39B Piston 1
40B Piston Pin 1
41B Connecting Rod 1
42B Crankcase 1
43B Crankcase Cover Gasket 1
44B Bearing 6205 1
45B Crankshaft 1
46B Dipstick 1
47B Bolt M6 x 35 1
48B Oil Return Seal 1
49B Washer Φ25.4 x Φ34 x 1 1
50B Drain Bolt Washer M10 x 1.25 x 15 1
51B Washer Φ10 x 1.5 x Φ16 1
Part Description Qty.
52B Dowel Pin Φ9 x 14 1
53B Crankcase Cover 1
54B Bolt M6 x 28 7
55B Oil Seal Φ25 x Φ38 x 7 1
56B Dowel Pin Φ7 x 14 1
57B Governor Gear 1
58B Governor Gear Mounting Plate 1
59B Ground Wire 1
60B Governor Spring 1
61B Engine Switch 1
62B Governor Gear Bracket Assembly 1
63B Governor Lever 1
64B Choke Lever 1
65B Shield Block 1
66B Bolt M6 x 12 2
67B Vent Hose 1
68B Cotter Pin 1
69B Oil Seal Φ6 x Φ11 x 4 1
70B Governor Gear Shaft 1
71B Wire Clamp 1
72B Idle Spring 1
73B Throttle Linkage 1
74B Fuel Hose Φ6.3 x Φ12.5 x 300 1
75B Fuel Hose Clamp 2
76B Fuel Filter 1
77B Fuel Tank Gasket 2
78B Fuel Tank 1
79B Vibration Pad 1
80B Fuel Tank Damping Pad 1
81B Tank Nut 1
82B Fuel Cap Inner Cover 1
83B Fuel Cap 1
84B Ignition Module 1
85B Shield Block 1
86B Bolt M6 x 25 2
87B Second Air Valve 1
88B Breather Valve Spring 1
89B Breather Screen 1
90B Oil Seal Φ22 x Φ35 x 6 1
91B Oil Filter Gasket 1
92B Breather Cover 1
93B Flywheel 1
94B Cooling Fan 1
95B Starter Cup 1
96B Nut M14 x 1.5 1
97B Stud M6 x 74 1
98B Stud M6 x 78.5 2
99B Blower Housing 1
100B Nut 3
101B Recoil Starter 1
When ordering replacement parts from this list, the “B” suffix must be included in order to get the correct part.
