Parts Lists and Diagrams
General Parts List
Part Description Qty.
1 Wand 1
2 Spray Gun 1
3 Spray Gun Holder 1
4 Knob 2
5 Handle 1
6 Handle Grip 1
7 Hose Hanger 1
8-1 Red Nozzle – 0° 1
8-2 Yellow Nozzle – 15° 1
8-3 Green Nozzle – 25° 1
8-4 White Nozzle – 40° 1
8-5 Black Nozzle – Detergent 1
9 Nozzle Grommet 5
10 Bolt 4
11 Nozzle Panel 1
12 Handle Knob 2
13 Frame 1
14 Wand Holder 2
Part Description Qty.
15 Pressure Hose 1
16 Bolt 2
17 Pin 2
18 Washer 4
19 Axle 2
20 Wheel 2
21 Gasket 1
22 Rubber Pad 1
23 Bolt 1
24 Detergent Tank 1
25 Detergent Tank Lid 1
26 Detergent Tube 1
27 Key 1
28 Pump 1
29 Engine Mounting Bolt 3
30 Engine 1
31 Flange Nut 3
32 Bolt 1
