Page 26 For technical questions, please call 1-888-866-5797. ITEM 62201
SAFETY SETUP OPERATION MAINTENANCE
Pump Parts List
Part Description Qty.
1A Nut M6 1
2A Grub Screw M6 x 16 1
3A Handle Insert 1
4A Plate Spring 2
5A Spring 1
6A Piston 1
7A O-Ring Ø6.02 x 2.62 1
8A O-Ring Ø6.07 x 1.78 1
9A Ring 1
10A Piston Guide 1
11A O-Ring Ø14 x 1.78 5
12A O-Ring Ø10.82 x 1.78 1
13A By-Pass Jet 1
14A Seat 1
15A O-Ring Ø9 x 1 1
17A Hose Nipple 1
18A O-Ring Ø4.48 x 1.78 1
19A Ball 1
20A Spring 1
21A Screw 1
25A Plug 3
26A Check Valve 6
27A Pump Head 1
28A Gasket 3
29A Bushing 3
30A Seal 3
Part Description Qty.
31A Plug 1
32A Housing 1
33A Head Bolt M8 x 45 3
34A Inlet Fitting 3/4" NH 1
35A Inlet Extension 1
36A Filter 1
37A O-Ring Ø4 x 2.5 1
38A Jet 1
39A Spring 1
40A O-Ring Ø8.73 x 1.78 2
41A Detergent Injector 1
42A Outlet Extension 1
43A Spring 3
44A Piston 3
45A Ring 3
46A Thrust Washer 1
47A Bearing 1
48A Thrust Washer 1
49A Hollow Shaft 1
50A Bearing 1
51A Circlip Øi72 1
52A Seal 1
53A O-Ring Ø23.52 x 1.78 3
54A Bushing 3
55A O-Ring Ø14 x 2 2
56A O-Ring Ø4.48 x 1.78 1
When ordering replacement parts from this list, the “A” suffix must be included in order to get the correct part.
