STEP 13
Estimated Time: 5 minutes PER DRAWER
Insert cams into drawer sides
Screw green twister dowels into drawer fronts
13a
13b
D3
D2
D1
Left Drawer Side
Right Drawer Side
Make sure arrow
faces toward hole for
twister dowel
Page 16 of 20
