STEP 1
Attach T-spacers to left and right cabinet sides using drawer slide screws
Estimated Time: 15 - 25 minutes
1a
1a
1b
1b
Then, attach metal cabinet slides to T-spacers using drawer slide screws
Left
Cabinet
Side
Right
Cabinet
Side
T-spacer & Slide Detail
Drawer Slide Screw
Drawer
Slide
Screw
Page 4 of 16
C2
C3
Top
Front
