Prepac DC-6330-V - Main Frame Assembly - Step 4; Inserting Dowels and Rods for Connection; Connecting Frame Sections

Page 10 of 20
9
8
Note: molding
overhangs toward
the OUTSIDE
Note : la moulure
surplombe vers
l’extérieur
Moldura lateral
sobresale hacia la
parte exterior
C3
C5
x2
Plastic Dowel
Goujon en plastique
Clavija de plastico
x4
Blue Rapid Rod
Tige rapide bleu
Clavija azul de
ajuste rápido
x4
C7
C7
C7
C7
