Attach metal U-channels to each outer
gable using drawer slide screws
Drawer
Slide
Screw
Attach T spacers to outer gables with drawer slide screws.
STEP 2
Estimated Time: 15 minutes
Drawer
Slide
Screw
B1
B1
STEP 1
Estimated Time: 10 minutes
Page 4 of 20
