Page 5 of 20
Attach drawer glides to T-spacers on
outer gables as shown in the photo
Position the Drawer Glides with:
A) The wheel at the finished side
B) The wheel on the unfinished bottom
Finished
Side
Bottom
STEP 3
Estimated Time: 10 minutes
Use 1st hole
Use 14th hole
Use 1st hole
Use 14th hole
