Prepac SH-6656 - Step 4: Attach Fixed Shelf to Stabilizers

Page 6 of 16
STEP 4
Estimated Time: 5 minutes
Attach ONE SIDE ONLY to both stabilizers and to the fixed shelf. Tighten cams
slightly. Make sure the stabilzers and shelf are positioned squarely with the side.
Fully tighten cams using a flathead screwdriver.
Position the large fixed shelf as shown with the finished edge on the floor.
Left
Side
Fixed Shelf
Finished Edge
(Front)
Unlocked
Locked
Turn 210°
Tightening Cams
4a
4b
FRONT
