Headphone Outputs
Type ¼” TRS Female, Stereo, Unbalanced
Maximum Output Level 150 mW/channel @ 60Ω
Frequency Response 20 Hz to 20 kHz, ±0.3 dB
Dynamic Range (A-wtd) > 103 dB
THD+N (1 kHz, -1 dBFS, unwtd) < 0.005%
Crosstalk (1 kHz, channel-to-channel) < -80 dB
Internal Talkback Microphone (Studio 192 only)
Type Electret Condenser
Sensitivity -42 dB
Signal Level LEDs
Signal 1 -50 dBFS
Signal 2 -30 dBFS
Signal 3 -20 dBFS
Signal 4 -10 dBFS
Signal 5 -6 dBFS
Signal 6 -4 dBFS
Signal 7 -2 dBFS
Clip -0.5 dBFS
Digital Audio
Connection Type USB 3.0
ADC Dynamic Range (A-wtd, 48 kHz) 118 dB
DAC Dynamic Range (A-wtd, 48 kHz) 118 dB
Bit Depth 24 bits
Internally Supported Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
Clock
Jitter <50 ps RMS (20 Hz – 20 kHz)
Jitter Attenuation >60 dB (1 ns in => 1 ps out)
