128-9322
3/8
Page 3
2 Pin Door Lock Output Harness Part #1122242
11 Pin Main Wiring Harness Part # 1122910
1 WHITE (+) Parking Light Output 15A Max
2 RED (+) 12 Volt Input Parking Lts
3 DARK BLUE Channel 3 Trunk Output (-) 300mA
4 WHITE/BLACK + 12 Volts Siren Output
5 RED/WHITE + 12 Volt Module Feed (See Red)
6 BLACK Chassis Ground
7 YELLOW Ignition Input Switched +12 Volts
8 DARK GREEN Negative Hood / Trunk Trigger Input
9 BROWN Negative Door Trigger Input
10 PURPLE Positive Door Trigger Input
11 ORANGE Ground Output While Armed (-) 300mA
1 Red Negative Lock/Pos. Unlock 300mA Max
2 Green Positive Lock/Neg. Unlock
