22 Pin Main Wiring Harness #1124300
1 Green/White Dome Light Output (-)
2 LT. Blue Ground While Running Output (-)
3 Black/White Horn Output (-)
4 Purple (+) Door Trigger Input
5 Brown/Black (+) Inhibit /Shutdown To Brake Switch
6 DK. Blue/Black External Remote Start Trigger input (-)
7 Orange/Black (-) Parking Brake Input
8 Green/Yellow Glow Plug Input
9 Brown (-) Door Trigger Input
10 Green/Orange Tachometer input
11 DK. Green (-) Instant Trigger Input
12 DK. Blue Channel 3 Trunk Release Output (-)
13 Green/Black Channel 4 Output (-)
14 DK. Blue/Red Channel 7 Output (-)
15 Black/LT. Green Pulse After Start Output (-)
16 Black/Blue Pulse Before Start Output (-)
17 Black/Red Pulse After Shut Down Output (-)
18 Black/Yellow Pulse During Crank Output (-)
19 LT. Blue/Black Channel 6 Output (-)
20 LT. Blue/Green Channel 5 Output (-)
21 Gray/Black (-) Inhibit / Shutdown To Hood Switch
22 Orange Starter Inhibit Relay Control (-)
