32
www.pridemobility.com Colt Series
VI. COMFORT ADJUSTMENTS
Figure 16. Seat Position Adjustments
SEAT ROTATION ADJUSTMENT
The seat rotation lever will secure the seat into
several positions.
1. Push forward on the seat rotation lever to disen-
gage the seat. See figure 16 or 18.
2. Rotate the seat to the desired position.
3. Release the lever to secure the seat into place.
SEATBACK ADJUSTMENT
WARNING! Do not operate your scooter
with the seatback in a reclined position.
WARNING! Always keep your back
pressed firmly against the seatback
while adjusting the angle.
If you scooter is equipped with a reclining seatback,
you can adjust the seatback angle with the seatback
adjustment lever. See figure 17.
1. With your back pressed up against the seatback,
lift up on the seatback adjustment lever and lean
forward or rearward to adjust the seatback angle.
2. Release the seatback adjustment lever once the
seat is in a comfortable riding position.
FRONT-TO-BACK SEAT ADJUSTMENT
If your scooter is equipped with an adjustable seat,
you can reposition the seat forward or rearward.
1. Move the seat sliding lever located at the lower
left side of the seat outward. See figure 18.
2. While holding the lever out, slide the seat for-
ward or rearward.
3. Release the seat sliding lever once the seat is in
the desired position.
SEAT ROTATION LEVER
Figure 17. Seatback Adjustment
SEATBACK
ADJUSTMENT
LEVER
Figure 18. Seat Position Adjustments
ADJUSTMENT DIAL
SEAT SLIDING LEVER
SEAT ROTATION LEVER
