44
www.pridemobility.com Colt Series
APPENDIX I - SPECIFICATIONS
COLT NINE
Model Number SC709
Class Of Use B
Maximum Safe Slope 14.1% (8°)
Maximum Climbing Ability 14.1% (8°)
Obstacle Climbing Ability 5 cm (2 in.)
Overall Length
2
115.57 cm (45.5 in.)
Overall Width
2
57.15 cm (22.5 in.)
Total Weight Without Batteries
2,6
59.42 kg (131 lbs.)
Heaviest Piece When Disassembled Front Section: 26.8 kg (59 lbs.)
Turning Radius
2
130.81 cm (51.5 in.)
Speed (Maximum)
1
Up to 6.43 km/h (4 mph)
Range Per Charge
1, 4
21 km (13 miles)
Ground Clearance
2
5.7 cm (2.25 in.) at mid-frame
Weight Capacity 147.42 kg, 23 stone (325 lbs.)
Standard Seating Type: Foldable Molded Plastic
Weight: 12.7 kg (28 lbs.)
Material: Black Vinyl
Dimensions: 45.72 cm (18 in.) overall width
43.18 cm (17 in.) effective depth
Drive System Rear-wheel drive, sealed transaxle, 24-volt DC motor
Dual Braking System Regenerative and electromechanical
Tires Front and Rear: 22.86 cm (9 in.) solid
Battery Requirements
3, 5
Two 12-volt, deep-cycle
Size: U1
U1 Battery Weight: 11 kg (24.5 lbs.) each
Battery Charger 5-amp, off-board
1
Varies with user weight, terrain type, battery amp-hour (Ah), battery charge, battery condition and tire condition. This specification can be
subject to a variance of (+ or -) 10%.
2
Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+ or – ) 3 %.
3
AGM or Gel-Cell type required. See V. “Batteries and Charging.”
4
Tested in accordance with ASNI/RESNA, WC Vol 2, Section 4 & ISO 7176-4 standards. Results derived from theoretical calculation based
on battery specifications and drive system performance. Test conducted at maximum weight capacity.
5
Battery weight may vary based on manufacturer.
6
Includes standard seat.
NOTE: This product conforms to all applicable ANSI-RESNA testing requirements and ISO 7176
series EN12184 standards. All specifications subject to change without notice.
