Table 3. J6 with Q-Logic Electronics Error Codes*
* Refer to the Q-Logic Error Code Reference Guide for additional error codes.
ERROR CODE DIAGNOSIS SOLUTION
#1 to #6: Software Fault Generic software or module error. Power joystick off/on. Check all module
connections. Update module software.
#19: Communication Fault Communication to a module
failed.
Power joystick off/on. Check all cable
connections. Update module software.
#23: Communication Fault
BUS cable unplugged while driv-
ing. BUS cable defective. Hard-
ware failure.
Power joystick off/on. Check all BUS cable
connections. Unplug device after device
from BUS cable until fault is resolved.
#36: Joystick Not Centered Joystick not centered at power up.
Release joystick. Power joystick off/on.
#37: Joystick Connection
Joystick disconnected or defec-
tive.
Ensure joystick is connected. If so,
replace joystick.
#105: Low Battery Fault Battery voltage below nominal
operating range limit. The battery
is not sufficiently charged.
Charge battery.
#192: Motor 1 Disconnected Motor connector unplugged.
Motor wiring open. Defective
motor.
Check motor brake connector. Check
motor wiring and resistance.
#193: Motor 2 Disconnected
Motor connector unplugged.
Motor wiring open. Defective
motor.
Check motor brake connector. Check
motor wiring and resistance.
#203: Brake 1 Disconnected
Motor connector unplugged.
Brake wiring open. Brake defec-
tive. The brake voltage is set too
low.
Check motor brake connector. Check
brake wiring and resistance.
#204: Brake 2 Disconnected
Motor connector unplugged.
Brake wiring open. Brake defec-
tive.
Check motor brake connector. Check
brake wiring and resistance.
#229: Module Missing or
Defective
Device not connected. Device is
defective. Wrong system configu-
ration data.
Reconnect device. Replace device. Save
system configuration.
