Pride Jazzy 1113 - III. YOUR POWER CHAIR

Jazzy 1113 www.pridemobility.com 13
III. Y OUR POWER CHAIR
YOUR POWER CHAIR
Your power chair has two main assemblies: the seat and the power base. See figure 5. Typically, the seating system
includes the armrests, the seatback, the seat base, and the controller. The power base assembly includes two drive
wheels, two anti-tip wheels, two rear caster wheels, and harness connectors. See figures 5, 6, and 7.
SEAT ASSEMBLY
Figure 5. The Jazzy 1113
SEATBACK
CONTROLLER
ANTI-TIP WHEELS
ARMRESTS
BODY SHROUD
FOOTREST
CASTER WHEEL
DRIVE WHEEL
SEAT FRAME LATCH
RELEASE BUTTONS
JOYSTICK
SEAT BASE
POWER BASE ASSEMBLY
