VII. OPERATION
Actuator Keys and Actuator Lights (for optional equipment on some models)
Actuator keys and actuator lights are used for optional equipment such as power elevating seats or power elevating
leg rests. Contact your authorised Pride Provider for more information.
OFF-BOARD CHARGER/PROGRAMMING SOCKET
You may use an off-board charger to charge the power chair batteries through the 3-pin socket located on the front
of the VSI. If you use an off-board charger, the charger current should not exceed 12 amps. Contact an authorised
Pride Provider for more information.
WARNING! Only chargers with Neutrik NC3MX plugs should be connected to the off-board
charger/programming socket. See an authorised Pride Provider for more information.
NOTE: The socket may also be used for reprogramming the VSI. Contact an authorised Pride Provider
for more information.
3-PIN CHARGER INHIBIT CONNECTOR
This connects the VSI to the onboard battery charger. This connection provides an inhibit that disables the VSI
when the battery charger is on. The charger inhibit connector is coded with colored dots. The dots are positioned
so that you align the flat side of the male connector with the flat side of the female connector before making the
connection. It is typically mounted next to the controller connector on the power base.
WARNING! Failure to properly align the connectors can result in damage to the VSI, the
charger harness, and the connectors.
CONTROLLER CONNECTOR
This connects the VSI to the power chair’s batteries, motors, and motor brakes. It is typically mounted on the
power base.
ACTUATOR CONNECTOR (FOR OPTIONAL EQUIPMENT ON SOME MODELS)
This connects the VSI to optional equipment such as a lighting system or a power elevating seat. It is typically
mounted on the power base.
LOCKING/UNLOCKING THE VSI
The VSI has a feature that enables you to lock your power chair to prevent unauthorised use.
To lock the VSI:
1. With the VSI powered on, press and hold the on/off key. After one (1) second, the VSI should beep.
2. Release the on/off key.
3. Push the joystick to the full forward position until the VSI beeps.
4. Pull the joystick to the full rearward position until the VSI beeps.
5. Release the joystick. There should be a long beep.
6. The VSI is now locked.
