34 www.pridemobility.com Jazzy 1113
VII. OPERATION
Battery Condition Meter
The battery condition meter consists of six lights arranged in an arc over the battery icon. From left to right, the first
two are red, the second two are orange, and the last two are green. These lights give you an accurate indication of
your usable battery capacity. If the battery has at least 85% of its rated capacity, all of the lights will be on. As the
battery voltage drops, the number of lights reduces from right to left. When the battery capacity drops to 10% or
below, all of the lights will flash once every second.
NOTE: When the battery capacity drops to below 21V (typically two lights), the controller will reduce
power chair performance to conserve battery power.
Drive Program Select Key
The drive program select key enables you to select a drive program and a power accessory mode. Your Europa
Controller was preprogrammed at the factory for five drive programs— 1 (slowest) to 5 (fastest). The drive mode
is indicated by a number in the center of the keypad (drive mode and actuator display).
NOTE: The drive mode settings are preset at the factory. If your authorised Pride Provider changes
these settings, please make note of these changes.
To change the drive program:
1. Press the drive program select key.
2. Move the joystick right to increase the drive program.
3. Move the joystick left to decrease the drive program.
4. Press the drive program select key.
Drive Mode and Actuator Display (also status display)
This is a 7-segment light that displays the drive program. It also displays a drive inhibit and actuator mode
(if applicable), when they occur.
System Status Light
This light will flash if there is an internal fault, or if an OONAPU fault has occurred. See “Out Of Neutral At Power Up.”
Horn Key
The horn key activates the horn.
CONTROLLER COMMUNICATIONS CONNECTOR
This connects the Europa to the power chair’s batteries, motors, and motor brakes.
OFF-BOARD CHARGER/PROGRAMMING SOCKET
You may use an off-board charger to charge the power chair batteries through the 3-pin socket located on the front
of the Europa. If you use an off-board charger, the charger current should not exceed 8 amps. Contact your
authorised Pride Provider for more information.
NOTE: The socket may also be used for reprogramming the Europa. Contact your authorised Pride
Provider for more information.
