36 www.pridemobility.com Jazzy 1113
Flash Code Sequence Diagnosis Solution
In the event of an error, the system status light displays diagnostic indications. Errors are encoded as follows: one
(for a low battery voltage fault) to twelve (module mismatch) and are displayed by the light flashing the number of
times prescribed by the error code. The flash sequence (one to twelve) is followed by a long off period (2 sec-
onds). If more than one error exists, then the error having the highest priority is indicated. The controller must be
turned off and then on again even if the source of the error is removed. If you cannot resolve the problem, contact
your authorised Pride Provider.
VII. OPERATION
•—•—•— DX module fault See your authorised Pride Provider.
••—••—••— DX accessory fault See your authorised Pride Provider.
•••—•••— Left motor (or connection) fault Check left motor wiring.
••••—••••— Right motor (or connection) fault Check right motor wiring.
•••••—•••••— Left park brake fault Check motor/brake wiring.
••••••—••••••— Right park brake fault Check motor/brake wiring.
•••••••—•••••••— Low battery fault Check that the battery wiring is secure.
•••••••—•••••••— Over voltage fault Check that the battery wiring is secure.
•••••••—•••••••— CANL fault See your authorised Pride Provider.
•••••••—•••••••— CANA fault See your authorised Pride Provider.
•••••••—•••••••— Stall timeout Turn unit on, then off.
•••••••—•••••••— Module mismatch See your authorised Pride Provider.
