11Legend
CONTROL CONSOLE MODULE
The control console module located on the front section houses all nthe controls you need to operate your Scooter.
See figure 7.
WARNING! Do not expose the control console module to moisture. In the event it does become
exposed to moisture, do not attempt to operate your Scooter until it has dried thoroughly.
IV. DESCRIPTION
Your Scooter is a motorized electric vehicle designed to enhance your personal mobility. It is an indoor/outdoor
Scooter that was designed to travel primarily on smooth surfaces such as pavement, roads, parking lots, floors, and
driveways. For easy transportation or storage, you can disassemble your Scooter into seven components. See
figure 6.
FIGURE 7. CONTROL CONSOLE MODULE
BATTERY CONDITION METER
SPEED ADJUSTMENT DIAL
KEY SWITCH
STATUS LED
LIGHT SWITCH
RIGHT TURN INDICATOR
BUTTON
THROTTLE CONTROL
LEVER (FORWARD)
HAZARD LIGHT SWITCH
HORN BUTTON
LEFT TURN INDICATOR
BUTTON
THROTTLE CONTROL
LEVER (REVERSE)
HORN BUTTON
FIGURE 6. LEGEND COMPONENTS
BATTERIES
REAR SECTION
FRONT SECTION
SEAT
REAR SHROUD
FRONT BASKET
