IX. TROUBLESHOOTING
Any electromechanical device requires occasional troubleshooting. However, most problems that arise can usually
be solved with a bit of thought and common sense. Many of these problems occur because the batteries are not
fully charged or because the batteries are worn down and can no longer hold a charge.
DIAGNOSTIC FLASH CODES
Diagnostic flash codes help you perform basic troubleshooting quickly and easily. A diagnostic flash code will flash
from the status LED in the event one of the conditions listed below develops.
NOTE: Your Scooter will not run unless the flash code condition is resolved and the Scooter has been
powered down and then powered back up..
What if all the systems on my Legend seem to be dead?
n Make certain that the key is in the on position.
n Check that the batteries are fully charged. See V. Batteries and Charging.
n Push in the the main circuit breaker reset button. See IV. Description.
n Make certain that both battery harnesses are firmly connected to the rear electronics module and to the
battery terminals. See VIII. Disassembly and Assembly.
n Make sure that the silver front-to-rear harness is firmly connected to the rear electronics module. See VIII.
Disassembly and Assembly.
n Be sure the auto shutoff feature hasnt been activated. See V. Batteries and Charging.
n Check the fuses. See X. Care and Maintenance for fuse replacement.
What if the motor runs but my Legend does not move?
n With the key turned to the on position, check the status LED. If the LED flashes three times, a short pause,
then two times, this is the manual freewheel lever code and means your Legend is in manual freewheel mode.
n When the manual freewheel lever is pulled up, the brakes are disengaged and all power to the transaxle is
cut.
n Push down the manual freewheel lever to restore normal operation to your Legend. See IV. Description.
FLASH CODE CONDITION SOLUTION
n n n n n
Batteries are too low to operate the
Scooter or the charger is operating.
Charge batteries or unplug the charger power
cord from the electrical outlet.
n n
Controller is hot; the Scooter seems to
be losing power.
Shut down your Scooter for a minimum of
s
everal minutes to allow the controller to
cool.
n n n n
Wigwag fault; your throttle control
levers are not responding.
Call your authorized Pride provider for
assistance.
n n n n n
The manual freewheel lever is in the
(up) freewheel position.
Turn the Scooter key to the off position, then
p
ush
t
he freewheel lever to the (down) drive
position, restart your Scooter.
n n n n n n
Scooter is operating with the charger
attached.
Unplug the charger cord from the charger
power cord receptacle.
