27Legend
FIGURE 20. UNPLUGGING THE BATTERY HARNESSES
FIGURE 21. LIFTING THE BATTERY
FIGURE 22. UNPLUGGING THE FRONT-TO-REAR
CONNECTOR
FIGURE 23. REMOVING THE BALL DETENT PIN
VIII. DISASSEMBLY AND ASSEMBLY
FIGURE 24. UNLOCKING THE CAMLOCK LEVERS
FIGURE 25. SEPARATING THE FRAME SECTIONS
