PRIMA p. 10
MOVABLE SPOT WELDER
This machine complies with the 89/392/CEE directives and subsequent modifications and
supplements.
WELDING CONTROL.
Micro Digital 1 microprocessor-controlled welding control.
Machine starting is made switching the light button. The default operative mode is manual.
To change in automatic mode it is necessary to switch on the machine and pressing at the same
time the button on the gun.
1) “MR” WELDING SELECTOR
Activates the “MR” welding function. Welding time of 1 at 10 cycles, current at 100%.
2) TIP WELDING SELECTOR
Activates the tip welding function. Welding time of 1 at 10 cycles, cold welding, current at 85%.
3) PULSE HEATING SELECTOR
Activates the metal heating function with a copper electrode and pulse process. Heating current of
30% at 100%.
4) CARBON ELECTROD HEATING SELECTOR
Activates the heating function for metal heating operations using the carbon electrode. Heating
current of 15% at 60%.
5) WELDING OR HEATING SELECTOR
Activates the welding function with single spot process for screws, rivets and so on, and heating of
the metal with a copper electrode. Welding or metal heating time of 5 at 30 cycles, current at
100%.
5 1
2
3
4
