PRIMA p. 06
MOVABLE SPOT WELDER
This machine complies with the 89/392/CEE directives and subsequent modifications and
supplements.
TECHNICAL SPECIFICATIONS AND PERFORMANCES
Table of general technical data:
DIMENSIONS MICROCAR 28
Head WxLxH mm 145x320x250
Welding cable with easy start gun mm 3000
Earth cable mm 2000
Cable section mm² 50
Weight Kg 13
ELECTRICAL specifications MICROCAR 28
Nominal power at 50% KVA 2
Input voltage (*) 1ph V/Hz 230/50
Secondary no-load voltage V 7
Secondary short-circuit current KA 2.8
Secondary welding current KA 2,5
Duty cycles % 5
Rated power KVA 16
Fuses A 16
MECHANICAL FEATURES MICROCAR 28
Noise level (ISO 7779) dBA <65
Ambient temperature °C 55÷35
Air humidity % <90
Fig. 1
